Major characteristics
1. The is a new-generation quantitative filling and capping machine .
2. Capping part with inlet bottle ,sorting cap , feeder cap ,capping and outlet bottle makes . Dispatchjing cap in high speed . Bottle and cap can operate sunchronously .With supermatic productivity and high automation , the rotary piston machine is new-generation quantitative one .
3.This machine is an integration of mechanics and electrics . It is automatically controlled by PLC and touch screen controlled panel . It is an ideal model which integrates mechanic , electric ,light and gas . The machine has exceeded the top level of the similar type Bottles and caps are not injured buring capping ,It can compare abjistment with the foreign similar products . It is charectenrized by its long-time compoents , stable running, low noise ,large range and high efficiency . The surface has been polished and biaufiful .this machine adopts stepless . It is idea for small ,medium , large packaging workshop . During the work , the key parts are protected . If there is anything abnormal it will automatically stop and alarm ,then the touch screen will hint the abnormal part’s whereabouts its efficient design of water-proof frame and pneumatic motion ensure the enwiroment ot wokshop is not polluted .
Main performance parameter
1.dimension (L*W*H):3500mm*2200mm*2200mm
2.Filling head :20
3.Capping head :8
4.Suitable bottle :diameter :Φ40mm-Φ110mm
5.Height : 80mm-320mm
6. Packaging specification : 50ml - 1000ml
7.Production capacity :≤8000 b/h
8.Filling error :50-200m< 1ml , 200ml -1000ml < 2ml
9. Power supply :380V
10.Main machine power :7KW
11.Air consumption :0.4-0.65MPa clean and stable compressed air
Specifically for the agrochemical enterprises to provide the most provincial, most stable, most advanced packaging smart line, and strive to make Tom's products achieve practical, beautiful, humane, stable, thick and solid, humanization, to make due contributions for China and the world's.
